Seawater Cooling Yacht Marine Air Conditioner
Seawater Cooling Yacht Marine Air Conditioner

Seawater Cooling Yacht Marine Air Conditioner

marine use consists of all kinds of passenger ship,cargo ship,naval vessel and oil platform. using rivet stainless steel metal structure, and nickel-copper coaxis tube as heat exchanger for sea water side.
Send Inquiry
Chat Now

Product Features:


Seawater Cooling Yacht Marine Air Conditioner has standard stainless steel, using rivet stainless steel metal structure, and nickel-copper coaxis tube as heat exchanger for sea water side. The fan duct can be roted as required when you install it. The fan blower has advantage such as high static pressure, big air flow and low noise. Seawater Cooling Yacht Marine Air Conditioner has the maximum compact design and better performance. As customer required, we can also provide D-smart control PCB with soft-start function to minimize the starting current.


Product description:


                           Seawater Cooling Yacht Marine Air Conditioner (Water-Air)

Model NO.

MWL



Cooling capacity

kW

19-258


Power supply


220V~380V/3PH/50-60Hz


Fan data

Air flow

m3/h

1600~38500

External static pressure

Pa

80-850


Noise level

dB(A)

50~73


Motor power

kW

0.3~22


Refrigerant

Type

R22/R407c/R410a


Compressor

Type

Type

Hermetic Scroll

Rated power

kW

2.25~66


Water side heat exchanger

Type

Type

Alpaka & SS316 Tube plate & end cap Shell and tube

Water flow

m3/h

2.3~42


Water pressure drop

mH2O

2.3~6.3


Pipe connection

in/mm

DN25/32/40/50/65


Air side heat exchanger

Type

Copper tubes with aluminium fins or copper fins


Unit Dimensions

L*W*H

mm

750x550x1600~3500x1700x2000

Note:




1. Nominal cooling condition: indoor air temperature 27℃DB/19.5℃WB; seawater   inlet/outlet temperature 32℃/37℃.


water cooled ac unit


	 iso certification seawater cooled air conditioner

commercial seawater cooled air cooler


Seawater cooled air conditioner 120000btu



FAQ:


Q1:How about the quality of your product?

A1:Our products strictly manufatured according to national and international standard. We got ISO quality and CE,CCS,SGS…etc.


Q2: What's the MOQ?

A2:Usually for small units the MOQ is 5 sets, for big one the MOQ can be 1 set.


Q3:What's the terms of delivery?

A3: EXW, FOB, CFR, CIF.


Q4: How about the delivery time?

A4: About 25-30 days after the receipt of deposit and confirmation on all designs based of normal condition.
