Product Features:
1. Marine ship air cooler with compact design and light weight. Easy to place with lower height.
2. Marine ship air cooler is reverse cycle model equipped with air cooling and heating.
3. Compressor with the function of high-efficiency, low-vibration and low-electricity consumption
4. Condensers coil with high-efficiency spiral double tube allows high-heat exchange rate
5. Marine ship air cooler is freely adjustable air outlet
6. Rust resistant components by using stainless, aluminum and ABS plastic
7. New collection of drain minimize over-flow caused by drain movement
8. Smoother drain is available by placing the best location at installation
Product description:
Sea-water cooled Package Unit(Water-Air) | |||
Model NO. | MWL | ||
Cooling capacity | kW | 19-258 | |
Power supply | 220V~380V/3PH/50-60Hz | ||
Fan data | Air flow | m3/h | 1600~38500 |
External static pressure | Pa | 80-850 | |
Noise level | dB(A) | 50~73 | |
Motor power | kW | 0.3~22 | |
Refrigerant | Type | R22/R407c/R410a | |
Compressor | Type | Type | Hermetic Scroll |
Rated power | kW | 2.25~66 | |
Water side heat exchanger | Type | Type | Alpaka & SS316 Tube plate & end cap Shell and tube |
Water flow | m3/h | 2.3~42 | |
Water pressure drop | mH2O | 2.3~6.3 | |
Pipe connection | in/mm | DN25/32/40/50/65 | |
Air side heat exchanger | Type | Copper tubes with aluminium fins or copper fins | |
Unit Dimensions | L*W*H | mm | 750x550x1600~3500x1700x2000 |
Note: | |||
1. Nominal cooling condition: indoor air temperature 27℃DB/19.5℃WB; seawater inlet/outlet temperature 32℃/37℃. | |||
FAQ:
Q1：What is your company's after-sales service?
A1：Our warranty period is one year. If there is any problem in this year, we can send you the new parts for replacement. Meanwhile, welcome to consulting the technical knowledge.
Q2: Is it possible to make our logo on the product?
A2：Yes, OEM is available,including special style,color,logo,packing etc.
Q3：Can you produce according to the samples?
A3: Yes, we can produce by your samples or technical drawings.
Q4: How about the delivery time?
A4: About 25-30 days after the receipt of deposit and confirmation on all designs based of normal condition.
