Working principle:
Factory Price Long Life Precision Air Conditioning is both supply fan and exhaust fan are built inside to bring in fresh air and exhaust out the stale indoor air as well, thus to keep indoor space in natural comfort.
Factory Price Long Life Precision Air Conditioning is built-in heat exchanger (rotary heat exchanger or plate heat exchanger) transfers energy contained in the outgoing indoor air to the coming fresh air, thus fresh air is pre-cooled or preheated.
Factory Price Long Life Precision Air Conditioning is various functional sections such as filter section, cooling/heating section, humidifying section etc. can be combined together to meet different air treatment requirements.
Technical specification:
Room precision air conditioner | ||||
Model No. | JH/JHF | |||
Unit Performance | Cooling Type | Water-cooled/Air-cooled | ||
Cooling capacity | kW | 6.71~146 | ||
Electric heating capacity | kW | 4.5~56 | ||
Cooling consumed power | kW | 2.7~50.3 | ||
Air flow | m3/h | 2200~34000 | ||
External static pressure | Pa | 30~80 | ||
Power supply | 220/380/460V-3N-50/60Hz | |||
Refrigerant | R22/R407c/R410a | |||
Indoor unit | Fan | Fan way | Upper/Front/Down supply | |
Motor power | kW | 0.18~11 | ||
Humidification | Humidifying | Kg/h | 4~25 | |
Power | kW | 3.7~18.75 | ||
Noise level | dB(A) | ≤53~72 | ||
Model No. | SW | |||
Outdoor unit | Compressor | Type | Rotor/Scroll | |
Power | kW | 2.25~36 | ||
Condenser type | Copper tube aluminum fins | |||
Blower power | kW | 0.37~4.4 | ||
Noise level | dB(A) | ＜62~69 | ||
Connection tube | Gas tube(mm) | Φ12.7/Φ15.9/Φ19.1 | ||
Quantity | 1~5 | |||
Liquid tube(mm) | Φ9.52/Φ12.7 | |||
Quantity | 1~5 | |||
Connection | Flare opening | |||
Note: | ||||
1. Return air vent are equipped with G4 air filter. | ||||
2. Control temperature range between 18-32℃,accuracy of ±0.5℃ | ||||
3. Humidity control range of 40~80%, with an accuracy of ± 3% | ||||
4. Compressors are put indoor units. | ||||
FAQ:
Q1：Are you a manufacturer or trading company?
A1：We are a manufacturer which specialized in produce HVAC product since 2001.
Q2：What is your company's after-sales service?
A2：Our warranty period is one year. If there is any problem in this year, we will send you the new parts for replacement. Meanwhile, welcome to consulting the technical knowledge.
Q3: How about the quality of your product?
A3: Our products strictly manufatured according to national and international standard. We got ISO quality and CE,CCS,SGS…etc.
Q4：What types of payment do you accept?
A4：We accept T/T, L/C, more pay channels are open. 30% Deposit, 70% balance should be paid before shipment.
