Product Feature:
Head-Power split air conditioners are our hit products.With years of susbtained improvement,the units are now endowed with numberous merits such as high energy efficiency ratio,low noise,high static pressure,high control precision,safety,reliability,low vibration,high sealing property,excellent resistance agianst corrosion,rain,dust as well as easy installation and graceful appereance etc.They are widely used for villas,stations,large-scale conference,workshops,CBD and other commercial area.
Easy operation line controller:
• Cooling/Heating/Fan/Auto
• Free Blow/Duct Type Split Air Conditioner Error indication
• Timing On/Off
• Free Blow/Duct Type Split Air Conditioner Multi safety protection
• High/low pressure protection
• Free Blow/Duct Type Split Air Conditioner Overheat protection
• Current overload protection
• Free Blow/Duct Type Split Air Conditioner Phase sequence relay
• Free Blow/Duct Type Split Air Conditioner Time delay and antifreeze switch
Product description:
Free Blow/Duct Type Split Air Conditioner | |||
Indoor Model No. | HAM / HAD / HAL | ||
Unit Performance | Cooling Capacity | kW | 7.8~250 |
Air Flow | m3/h | 1350~35000 | |
Power Supply | 220V/380V/415V/440V-3N-50Hz/60Hz | ||
Refrigerant | R22/R407c/R410a/R134a | ||
Indoor Unit | Evaporator | Copper tubes with aluminum fins | |
Fan and Motor | Fan Type | Ultra-low-noise Centrifugal | |
Power | kW | 0.3~20 | |
Start Method | Direct-drive | ||
Connecting Method | Flare opening | ||
Outdoor Model No. | SW | ||
Outdoor Unit | Compressor | Type | Hermetic scroll compressor |
Power | kW | 2.25~72 | |
Condenser Type | Copper tubes with aluminum fins | ||
Condenser Fan | Type | Ultra-low Axial fan | |
Power | kW | 0.37~8.8 | |
Connecting Copper Tubes | Gas tubes | Size(mm) | Φ19.1/Φ28 |
Quantity | 1~8 | ||
Liquid tubes | Size(mm) | Φ12.7/Φ15.9 | |
Quantity | 1~8 | ||
Connecting Method | Flare opening | ||
FAQ:
Q1：What's the terms of delivery?
A1：EXW, FOB, CFR, CIF.
Q2：How do you ensure the quality of products?
A2：Quality and integrity is our corporate culture, each product will pass strict inspection to the factory.
Q3：Do you test all your goods before delivery?
A3：Yes, we have 100% test before delivery.
Q4：How about the delivery time?
A4：About 25-30 days after the receipt of deposit and confirmation on all designs based of normal condition.
