Greenhouse Rotor Heat Recovery Air Handling Unit

Name: China Customized Greenhouse Rotor Heat Recovery Air Handling Unit Manufacturers - Low Price - Head-Power
Brand: Head-Power
SKU: 105520914

High-efficiency filter. High-efficiency heat recovery core( Cross counter flow). Unit Function: Air purification, energy recovery, cooling, heating, control humidification.

Send Inquiry

Chat Now

Proudct Introduce

Greenhouse Rotor Heat Recovery Air Handling Unit researched and produced by Head-Power can not only discharge indoor dirty air into the outdoor air, but also send fresh air into the indoor air. Greenhouse Rotor Heat Recovery Air Handling Unit advanced energy recovery technology is adopted to convert energy by using the temperature and humidity difference between indoor and outdoor, so that ventilation can be achieved and indoor pollution can be solved. Greenhouse Rotor Heat Recovery Air Handling Unit can also keep the indoor temperature and humidity basically unchanged, perfectly solving the contradiction between fresh air and energy consumption.

Proudct Features

High-efficiency filter
High-efficiency heat recovery core( Cross counter flow)
Unit Function: Air purification, energy recovery, cooling, heating, control humidification.
Application: Meeting room, test room, office building,computor room, restaurant, shop, fitness and entertainment place etc.

Technical Specification

Technical Spe. For Rotor Type Heat Recovery Air Handling Units
Model Type		ZQH
Air Volume	m³/h	1000-150000
ESP	Pa	150-650
Rotor Specification	mm	500200-3600200x2
Rotor Resistance	Pa	138/166
Drive Motor Power	kW	0.12-0.25-0.5-0.75
Recovery Efficiency	%	78-80
Exhaust Fan Power	kw	0.55-60
Fresh Air Fan Power	kw	0.55-60
Filter Section		G4 F7 H13
Power Supply		380V/3PH/50Hz
Note:
1. Double skin panel, 30mm thickness PU insulation, galvanized steel sheet inner and powder coated sheet outside.
2. The unit doesn't include electric controller.
