15000cmh rotor hrv ventilation system

Filtration class range from G2-H14.

Preliminary filter: 350mm chemical fiber non-woven fabric, filtration efficiency G3 ~ G4.

Medium filter: bag, chemical fiber or glass fiber filter cloth, filtration efficiency F6 ~ F8.

Sub-HEPA filter: e ultra-fine glass fiber filter cloth, filtration efficiency is F9.

HEPA filter:high air volume ultra-fine glass fiber filter cloth, filtration efficiency H12 ~ H14.

cooling coil water baffle

◇High quality three-phase asynchronous motor,

protection class ≥ IP55, insulation class F-class.

◇Humidifiers: wet film humidification, electrode humidification, dry steam humidification, high pressure spray humidification, high pressure micro-mist humidification, secondary steam humidification etc.

◇Flexible opening and good sealing performance access door in each functional section.

◇The fan and the motor are fixed on the high-strength steel frame, and are equipped with reliable damping device, the motor fixed place is with sliding chute, for adjusting belt tightness.

Model type			ZQH15
Air Volume		m3/h	15000
ESP		Pa	350
rotor specification		mm	1600
rotor resistance		Pa	100
drive motor power		kW	0.3
recovery efficiency		%	72
exhaust fan power		kw	7.5
fresh air fan power		kw	7.5
fresh air Filter section	Pre-filter		G4 plate filter
	Medium filter		F7 bag filter
	HEPA filter		H12
Power supply			380V/3PH/50Hz
