40ton hvac air handle unit
| Model No. | HHAC50 | |||
| Unit performance | Cooling capacity | kW | 140 | |
| Heating capacity | kW | 150 | ||
| electric heating | kW | 30 | ||
| Air flow | m3/h | 16200 | ||
| fresh flow | m3/h | 1800 | ||
| External static pressure | Pa | 350 | ||
| Electrode humidification | kg/h | 10 | ||
| Power supply | 380V/3N~50Hz | |||
| Refrigerant | R410A | |||
| Indoor unit | skin | type | double skin | |
| thickness | mm | 30 | ||
| mixing box | yeah | |||
| Filter | G4+F8 | |||
| Fan and motor | Fan type | low noise centriful type | ||
| Power | kW | 11 | ||
| Manual speed regulation of frequency converter | ||||
| Start method | belt drive | |||
| Outdoor unit | Model No. | SW50 | ||
| Compressor | Type | scroll | ||
| brand | danfoss | |||
| Power | kW | 18*2 | ||
| Condenser type | Copper tubes with aluminium fins | |||
| Condenser fan | Type | Axial fan | ||
| Power | kW | 0.9*4 | ||
| Dimensions(L*W*H) | mm | 2100*2000*2150 | ||
| Connecting copper tubes | Gas tubes | Size (mm) | Φ28 | |
| Quantity | 2 | |||
| Liquid tubes | Size (mm) | Φ19.1 | ||
| Quantity | 2 |
|
