(1) Ventilation Water Cooled Scroll Water Chiller consists of famous brand compressor;
(2) Ventilation Water Cooled Scroll Water Chiller adopts micro computer intelligent controller;
(3) Ventilation Water Cooled Scroll Water Chiller eauips with high efficiency heat exchanger;
(4) The chiller application area: Industrial chiller is widely applied in the industrial fields, such as daily chemical, electronics, food processing, pharmacy, injection molding, etc.
(5) The chiller has compact structure, elegant appearance, sufficient cooling capacity, high efficiency and maintenance easily.
Technical specification:
Water Cooled Scroll Water Chiller | |||
Model NO. | HWWC | ||
Cooling capacity | kW | 15-150 | |
Power supply | 220V-380V-460V/3PH/50Hz-60Hz | ||
Refrigerant | R22/R407c/R410a/R134a | ||
Compressor | Type | Hermetic scroll compressor | |
Safety measures | High&low pressure switch, internal overload protector, insufficient water protector, etc. | ||
Evaporator | Type | Shell and tube type | |
Inlet/Outlet water temp. | ℃ | 12/7℃ | |
water flow | m3/h | 3-27.5 | |
water pipe | DN | 25-50*2 | |
Condenser | Type | Shell and tube type | |
Inlet/Outlet water temp. | ℃ | 30/35℃ | |
water flow | m3/h | 3.3-34.5 | |
water pipe | DN | 25-50*2 | |
Note: | |||
1. Nominal cooling condition: evaporator inlet/outlet water temp. 12/7℃,condenser inlet/outlet water temp. 30/35℃. | |||
2. The unit doesn't include water pump and water tank.
| |||
FAQ:
Q1：How do you ensure the quality of products?
A1：Quality and integrity is our corporate culture, each product will pass strict inspection to the factory.
Q2：What types of payment do you accept?
A2：We accept T/T, L/C, more pay channels are open. 30% Deposit, 70% balance should be paid before shipment.
Q3: What about the warranty?
A3: The warranty is 18months after delivery.
