Tent Military Rooftop Package Central Air Conditioner can be Multi-function. OEM the function customer need: cooling and heating, constant temp. and humidity, different air filter or other functions. It is floor standing put outdoor. This type is very hot sale for these years as it is good design and engineer saving and multi-functions.
Features:
1. Tent Military Rooftop Package Central Air Conditioner is applicable for the regions in short of water.
2. Tent Military Rooftop Package Central Air Conditioner can be easily erected on the roof not take up indoor area.
3. Sufficient outside excessive pressure exists, easy for air duct ventilation, greatly reducing indoor noise;
Exclusive vertical and horizontal air supply structures are optional.
4. Complete varieties and specifications are satisfactory for different demands.
5. Large cold capacity unit is made of broken cold bridge aluminum alloy profile, prohibits the generation of cold leak or condensed water due to higher temperature difference in and out of the unit.
6. Major components are all overseas introduced excellent products.
7. The evaporator and condenser enjoy enhanced heat transfer design, being efficient and energy saving.
Technical specification:
Rooftop Packaged Unit | ||||
Model No. | WK | |||
Unit Performance | Cooling capacity | kW | 13~300 | |
Air flow | m3/h | 3000~50000 | ||
External static pressure | Pa | 150~1000 | ||
Power supply | 220/380/460V-3N-50/60Hz | |||
Refrigerant System | Refrigerant | R22/R407c/R410a/R134a | ||
Compressor | Type | Hermetic scroll compressor | ||
Power | kW | 4~87 | ||
Evaporator | Type | Copper tubes with aluminum fins | ||
Condenser | Type | Copper tubes with aluminum fins | ||
Air supply system | Condenser fan | Type | Ultra-low noise axial type | |
Drive method | Direct drive | |||
Motor power | kW | 0.37~15.4 | ||
Evaporator fan | Type | Double-inlet centrifugal | ||
Drive method | Belt drive | |||
Motor power | kW | 0.55~22.5 | ||
FAQ:
Q1：What's the MOQ?
A1：For small units the MOQ is 5 sets, for big one the MOQ can be 1 set.
Q2：How about the price of this product?
A2：This product can be different capacity and quantities, so you can contact me directly to know the accurate price.
Q3：How to choose a suitable machine?
A3: Tell us about your machine USES, we have professional designers will resolve for you.
