The aseptic room decoration design adopts a class 100 clean room, and the number of dust particles ≥0.5μm (mainly controlled particles) per cubic foot of air in the controlled area does not exceed 100. Other basic parameters are as follows: 0.1μm≤100000pc/m 0.2μm ≤23700pc/m 0.3μm≤10200pc/m 0.5μm≤3520pc/m 1μm≤832pc/m 5μm≤29pc/m Temperature: 20-22℃/humidity 30%-50% in winter, 24-26℃/humidity 50% in summer -70%; The pressure gradient between the clean rooms is not less than 5Pa, and the pressure difference between the clean area and the outdoor is not less than 10Pa; indoor noise: ≤60db(A)
The core clean area (level 100) of the negative pressure biosafety laboratory is designed with air-cooled heating and cooling ducted air-conditioning units to meet the temperature and humidity requirements of the controlled area environment throughout the year. The design layout is compact and reasonable, which meets the requirements of laboratory operation and air cleanliness level. At the same time, it strives for the principles of science and economy, and considers laboratory requirements and development and operating costs. The clean room needs to get a certain amount of fresh air nearby. The fresh air volume is the larger value of the fresh air required by the personnel * small fresh air and the positive pressure. After being purified and filtered by the medium efficiency cabinet, it enters each room to compensate for the positive pressure leakage air flow to ensure the positive pressure and The need for fresh air. All equipment adopts low-noise environmental protection equipment to ensure that the indoor noise in the core clean area (N5 level) is ≤60db(A).
