Proudct Features:
• The combination of Cleanroom Dehumidifier Heat Exchange Air Handling Unit is highly efficient energy-saving technology.
• Cleanroom Dehumidifier Heat Exchange Air Handling Unit rotary heat exchanger is common to have energy recovery rates between 70-90%.
• The rotor matrix temporarily takes up the heat from the warm air stream and releases it in the colder air stream.
• Cleanroom Dehumidifier Heat Exchange Air Handling Unit, dehumidification of warm and humid supply air to reduce the energy consumption of the down stream cooling equipment in summer. During winter operation this feature recovers moisture from the exhaust air to reduce the humidification load.
Technical specification:
Heat Pump Heat Recovery Air Handling Unit | |||
Model No. | HAX | ||
Nominal cooling capacity | kW | 9-216 | |
Nominal heating capacity | kW | 9.5-224 | |
Power supply | 220V-460V/3PH/50Hz-Hz | ||
Refrigerant | R22/R407c/R410a/R134a | ||
Compressor | Type | Hermetic Scroll | |
Power | kW | 1.7-36 | |
Exhaust air system | Air volume | m3/h | 1500-33000 |
ESP. | Pa | 100-550 | |
Motor power | kW | 0.55-15 | |
Fresh air system | Air volume | m3/h | 1000-20000 |
ESP. | Pa | 80-480 | |
Motor power | kW | 0.2-5.5 | |
Heat exchange efficiency | ＞87% | ||
Noise level | dB(A) | 48-68 | |
Dimensions | L*W*H | mm | 2000x1500x850 |
Net weight | kg | 380-1700 | |
