The Industrial Refrigerated Circulator Pump Water Chiller adopted world famous brand compressors and high efficiency condenser and evaporator, ensure high cooling efficiency, low energy consumption, low noise and long service life;
The Industrial Refrigerated Circulator Pump Water Chiller adopted aluminum fin/copper tube type condenser, easy for cleaning and installation;
5C to 35C optional temperature range;
Refrigerant gas can be R22, R407C, R410A and R134a, with high cooling efficiency;
Over sized evaporator and condenser ensure the chiller unit running under 45C high ambient temperature;
The Industrial Refrigerated Circulator Pump Water Chiller adopted microcomputer control system offering accurate temperature stability within ±1℃;
Low noise and big volume air blower;
Standard equipped Iron pump, stainless steel or high lift pump for option;
Multi-protection devices ensure the chiller unit running safely;
The innovative evaporator-in-tank configuration ensures a steady water temperature offered, as the evaporator also cools the tank itself, reduces ambient heat gain, and increases the efficiency.
Technical specification:
Air Cooled Scroll Water Chiller | ||
Model No. | HWAC | |
Cooling capacity | kW | 7-300 |
Power Supply | 220V-380V-460V/3N/50Hz-60Hz | |
Safety devices | High&low pressure switch, anti frozen protector, overload protector, phase order protector, internal overheat protection, water flow switch, etc. | |
Operation control | Microcomputer control automatically, abnormal warning, selfchecking, unit balance operation, remote control (optional), Timer on/off | |
Refrigerant | R22/R407c/R410a/R134a | |
Volume control | Thermostatic expansion valve | |
Compressor | Type | Hermetic Scroll Compressor |
Power | kW | 2.23-80 |
Air side heat exchanger | Fan type | Axial type |
Air direction | Top discharging | |
Fan power | kW | 6~30 |
Fan quantity | pcs | 2~6 |
Water side heat exchanger | Type | Shell and tube |
Water flow | m3/h | 1.6~46 |
Pipe connection | DN | 80~200 |
Cabinet material | Galvanized sheet | |
Unit dimensions L*W*H | mm | 800x500x1200~2800x2100x2150 |
FAQ:
Q1. Are you a manufacturer or trading company?
A1. We are a manufacturer which specialized in produce HVAC product since 2001.
Q2: How do you ensure the quality of products?
A2: Quality and integrity is our corporate culture, each product will pass strict inspection to the factory.
Q3. Your company can produce non-standard machine?
A3. Sure, our factory has 15 years experience in manufacturing, we also supply the machine based on the specification provided by the customers. You just need to give us parameters, our engineers will give you worked out the first time.
Q4: What types of payment do you accept?
A4: We accept T/T, L/C, more pay channels are open. 30% Deposit, 70% balance should be paid before shipment.
