Function Description:
1. Factory Price High Static Pressure Water Cooled Unit is constant temperature and humidity control
2. Air filter is easily dismantled and cleaned
3. Factory Price High Static Pressure Water Cooled Unit is remote control
4. Co-work setting
5. Factory Price High Static Pressure Water Cooled Unit complete fault alarm and protection systems
Technical specification:
Water cooled Package Unit(Water-Air) | |||
Model NO. | HWD/HWL | ||
Cooling capacity | kW | 10-258 | |
Power supply | 220V~380V/3PH/50-60Hz | ||
Fan data | Air flow | m3/h | 1350~38500 |
External static pressure | Pa | 0-850 | |
Noise level | dB(A) | 48~73 | |
Motor power | kW | 0.3~22 | |
Refrigerant | Type | R22/R407c/R410a | |
Compressor | Type | Type | Hermetic Scroll |
Rated power | kW | 2.25~66 | |
Water side heat exchange | Type | Type | Shell and tube |
Water flow | m3/h | 2.3~42 | |
Water pressure drop | mH2O | 2.3~6.3 | |
Pipe connection | in/mm | DN25/32/40/50/65 | |
Air side heat exchanger | Type | Copper tubes with aluminium fins | |
Unit Dimensions | L*W*H | mm | 750x550x1600~3500x1700x2000 |
Note: | |||
1. Nominal cooling condition: indoor air temperature 27℃DB/19.5℃WB; seawater inlet/outlet temperature 32℃/37℃. |
FAQ:
Q1：How about the quality of your product?
A1：Our products strictly manufatured according to national and international standard. We got ISO quality and CE,CCS,SGS…etc.
Q2：What's the payment terms?
A2: Usually T/T, L/C.
Q3：Are you a manufacturer or trading company?
A3：We are a manufacturer which specialized in produce HVAC product since 2001.
Q4：What about the warranty?
A4：The warranty is 18months after delivery.
