Product feature:
1. Air Cooled Explosion-proof Air Handler are known to know the cold heat, high speed intelligent air conditioning.
2. Air Cooled Explosion-proof Air Handler indoor unit with low noise design, quiet operation; key control and liquid crystal display make the operation of the unit more convenient.
3. Automatic operation mode, multiple protection, fault self-diagnosis, intelligent frost, low temperature start, timer function.
4. Air Cooled Explosion-proof Air Handler with brand expansion valve, in line with the flexible regulation of refrigerant flow, so that more reasonable operation.
5. The use of efficient spiral copper tube and hydrophilic aluminum fin, heat transfer efficiency, higher energy efficiency.
6. Apply to the oil, chemical, military, pharmaceutical, dangerous goods storage and other flammable and explosive industries.
Technical specification:
Explosion-proof Air Conditioner | |||
Indoor Model No. | HAM / HAD / HAL | ||
Unit Performance | Cooling Capacity | kW | 7.8~250 |
Air Flow | m3/h | 1350~35000 | |
Power Supply | 220V/380V/415V/440V-3N-50Hz/60Hz | ||
Refrigerant | R22/R407c/R410a/R134a | ||
Indoor Unit | Evaporator | Copper tubes with aluminum fins | |
Fan and Motor | Fan Type | Ultra-low-noise Centrifugal | |
Power | kW | 0.3~20 | |
Start Method | Direct-drive | ||
Connecting Method | Flare opening | ||
Outdoor Model No. | SW | ||
Outdoor Unit | Compressor | Type | Hermetic scroll compressor |
Power | kW | 2.25~72 | |
Condenser Type | Copper tubes with aluminum fins | ||
Condenser Fan | Type | Ultra-low Axial fan | |
Power | kW | 0.37~8.8 | |
Connecting Copper Tubes | Gas tubes | Size(mm) | Φ19.1/Φ28 |
Quantity | 1~8 | ||
Liquid tubes | Size(mm) | Φ12.7/Φ15.9 | |
Quantity | 1~8 | ||
Connecting Method | Flare opening | ||
