Product features:
Industrial 3hp To 100hp Cooling Split Air Conditioner is a kind of device that supplies treated air directly to the closed room or area. It mainly includes refrigeration system, air circulation and purification device, as well as heating, humidification and ventilation devices. It is an all-air system, which uses the heat exchanger in the refrigeration system to change refrigerant with air, so as to realize direct heat and humidity exchange. This operation has high efficiency as there is no energy loss brought by secondary exchange of intermediate heat transfer media; the non-aqueous system and various support equipment greatly reduce the system complexity and cost of initial investment. Also, industrial 3hp To 100hp Cooling Split Air Conditioner is a unit-type electro-mechanical device, without adding other complex control equipment, easy to install, operate and maintain and with low initial and later maintenance costs.
Industrial 3hp To 100hp Cooling Split Air Conditioner is diversified applications, comfortable and tranquil and high-quality indoor air provides. It can perform cooling rapidly and reach set temperature in a short time. With large heat exchange capacity, heating performance is strong and effective.
Technical specification:
Air Cooled Split Air Conditioner | |||
Indoor Model No. | HAM / HAD / HAL | ||
Unit Performance | Cooling Capacity | kW | 7.8~250 |
Air Flow | m3/h | 1350~35000 | |
Power Supply | 220V/380V/415V/440V-3N-50Hz/60Hz | ||
Refrigerant | R22/R407c/R410a/R134a | ||
Indoor Unit | Evaporator | Copper tubes with aluminum fins | |
Fan and Motor | Fan Type | Ultra-low-noise Centrifugal | |
Power | kW | 0.3~20 | |
Start Method | Direct-drive | ||
Connecting Method | Flare opening | ||
Outdoor Model No. | SW | ||
Outdoor Unit | Compressor | Type | Hermetic scroll compressor |
Power | kW | 2.25~72 | |
Condenser Type | Copper tubes with aluminum fins | ||
Condenser Fan | Type | Ultra-low Axial fan | |
Power | kW | 0.37~8.8 | |
Connecting Copper Tubes | Gas tubes | Size(mm) | Φ19.1/Φ28 |
Quantity | 1~8 | ||
Liquid tubes | Size(mm) | Φ12.7/Φ15.9 | |
Quantity | 1~8 | ||
Connecting Method | Flare opening | ||
FAQ:
Q1：What about the warranty?
A1：The warranty is 18months after delivery.
Q2：How about the quality of your product?
A2：Our products strictly manufatured according to national and international standard. We got ISO quality and CE,CCS,SGS…etc.
Q3：What's the MOQ?
A3：Usually for small units the MOQ is 5 sets, for big one the MOQ can be 1 set.
